BA series Functions Hydraulic bladder accumulator Design ASME

construction bottom-repairable Flow150gallons/min (GPM) / 568L/min (LPM) rated output flow Pressure3000psi / 206bar bladder gas pressure Capacity3.78L / 231in3 (cubic inch) / 1gallon Connection typeSAE-20 straight threaded inlet and outlet ports Dimensions171mm / 6.75" wide Material Buna-nitrile rubber (NBR) seals Chrome-Molybdenum alloy steel (SA372) body Ambient air temperature for operation-20°F...+200°F / -29°C...+93 °C
